Aircraft fire extinguishing systems: replacing the halon

The international civil aviation network carries over four billion passengers around the world annually. In celebrating ICAO's 75th Anniversary Celebrations, we will be highlighting some of the crucial safety achievements that have enabled this. We hope you follow our series throughout the year, and we encourage you to use the #ICAO75 hashtag to share your thoughts and memories with us through social media.


Traditionally, halogenated hydrocarbons (halons) have been the only fire-extinguishing agents used in civil transport aircraft as fire extinguishers because they are effective on different kinds of fires and they are very lightweight. However, due to their high ozone depletion, the Montreal Protocol on Substances that Deplete the Ozone Layer called for an end to their production by 1994 in developed countries and by 2010 in developing countries. As a result of this international agreement, production of halon is prohibited, and halon supplies are diminishing. The updated breakout of Global Inventories of Halon 1301 from the United Nations Environment Programme (UNEP) Halons Technical Options Committee (HTOC) 2018 Assessment Report is shown below.

Breakout of Global Inventories (Bank) of Halon 1301 by HTOC Model Regions. This chart was reproduced from the HTOC UNEP report (December 2018)

ICAO has mandated the use of Halon replacements in fire extinguishers used on civil transport aircraft. Several ICAO Provisions already exist in Annex 6 — Operation of Aircraft and Annex 8 — Airworthiness of Aircraft that stipulate requirements for the use of a non–halon alternate agent for fire suppression.

The Halon replacement cut off dates in ICAO SARPs contained in Annex 6 and 8:

Extinguishing systems in civil aircraft

ICAO SARP Cut-off date

Lavatory fire extinguishing systems

31 Dec 2011

Portable fire extinguishers 31 Dec 2018
Engine and APU fire extinguishing systems 31 Dec 2014
Cargo compartment fire extinguishing systems

28 Nov 2024

At present, halons are used for fire suppression on civil aircraft in four extinguishing applications as shown above. Worldwide, there are many States and organizations testing alternatives to halon. Unfortunately, there is no single substance which can be used for all of the extinguishing applications. Therefore, aviation will have to use different types of extinguishers for each application.

Lavatory fire extinguishing systems. Source: Aircraft Systems Tech

Halon replacement agent for portable and lavatory fire extinguishers which are reported to be neither a greenhouse gas nor an ozone-depleting substance are already available. Research and development are progressing towards halon replacement for engine and auxiliary power unit (APU) fire extinguishing systems. However, the industry is still far from developing a viable replacement agent for this application that can be fully tested, certified and implemented on commercial transport aircraft.  The cargo compartment extinguishers are the most difficult to replace, research and testing still have a long way to go. Halon replacement will require the full cooperation of all stakeholders to collaborate under the auspices of ICAO to achieve a viable solution which provides adequate technical performance, certification, and long-term environmental benefit.


Schematic of engine fire extinguishing system. Source: Bombardier Inc., with TSB modifications



Cargo compartment fire extinguishing systems. Source Aircraft Systems Tech

The 2018 HTOC model estimates the remaining worldwide bank of halon 1301 to be approximately 37,750 metric tonnes at the end of 2018 in accordance with Chapter 5 of the 2018 HTOC Assessment Report. This remaining bank of halon 1301 is assumed to be currently installed in fire suppression equipment (e.g., in aviation, computer facilities, oil and gas, military, maritime, etc.), as well as in available stockpiles. It is estimated that 12,500 metric tonnes of halon 1301 could become available to support civil aviation if all of it went only to civil aviation.  However, many other on-going uses of halon 1301 will also need to share in this available supply to meet their ongoing needs to refill discharged systems and/or leaks.


Portable fire extinguishers. Source: Crew Life Chronicles

The aviation industry continues to use halon today under an exemption to the international agreement because of its unique situation. This cannot and should not continue indefinitely.

Halon is currently available for aircraft use by recycling existing supplies; Although ICAO member States have taken measures to mitigate contamination, the potential risk of contamination of the reserves remains. In recognition of these issues and their potential impact on safety, transitioning promptly from halon to safe and effective halon alternatives now become urgent.
